| الاسم التجاري: | Sylaith |
| رقم الطراز: | 304/316/316L/321/309S/310S |
| الـ MOQ: | 1 Ton |
| السعر: | قابل للتفاوض |
| وقت التسليم: | 7-14 days |
| شروط الدفع: | L/C, T/T, Western Union |
Product Description:
ASTM A312 / A312M seamless, straight-seam welded, and cold worked welded austenitic stainless steel pipe intended for high-temperature and general corrosive service. Several grades of steel shall conform to the required chemical composition for carbon, manganese, phosphorus, sulfur, silicon, chromium, nickel, molybdenum, titanium, columbium, tantalum, nitrogen, vanadium, copper, cerium, boron, aluminum, and others. All pipes shall be furnished in the heat-treated condition in accordance with the required heat treating temperature and cooling/testing requirements. Tensile properties of the material shall conform to the prescribed tensile strength and yield strength. The steel pipe shall undergo mechanical tests such as transverse or longitudinal tension test and flattening test. Grain size determination and weld decay tests shall be performed. Each pipe shall also be subjected to the nondestructive electric test or the hydrostatic test.
| Outer Diameter | Seamless Pipe: 4mm-812.80mm |
| Welded Pipe: single slit (8mm-630mm);girth(630mm-3000mm), | |
| Thickness | Seamless Pipe: 0.3mm-60mm (SCH10S-XXS) |
| Welded Pipe: single slit (.05mm-25mm);girth(3mm-45mm), | |
| Length | 6m 5.8m, 8m, 11.8m, 12m, 13m or as required |
| Tolerance | According to the standard |
| Surface | 180G,320G, 400G Satin/Hairline |
| 400G, 500G, 600G or 8OOG Mirror finish | |
| Test | UT,ET,HT,RT, ect and others according to the standard or as per customer request |
| Certificate | ISO9001-2008, ASME, PED |
Steel Grade |
200 Series: 201,202 300 Series: 301, 304, 304L, 316, 316L, 316Ti, 309, 310, 317,321 400 Series: 409, 410, 420, 430, 436, 444, 441, 440c Duplex Steel : 904L, 2205, 2507, 2101, 2520, 2304 |
| Manufacturing Method | Cold Rolled, Hot Rolled |
| Manufacturing Technique | Seamless,Welded(ERW, EFW, Seamless, Spiral Welded) |
| Shape | Round, Square, Rectangular, Oval |
| Surface | Pickling, annealing, polishing, bright, sand blast, hair line,Primary, Bright Polished, Mirror |
Standards: |
ASTM A213M-94b, ASTM A249M-94a, ASTM A269-94a, ASTM A312M-94b, etc. |
| DIN 17456-85 DIN 17458-85 DIN 17459-92 etc. | |
| JIS G3446-1994 JIS G3448-1997 JIS G3459-1997 JIS G3463-1994 etc. | |
| GB13296-1991 GB14975-2002 GB14976-2002 etc. |
Chemical Composition:
| Grade | C | Mn | P | S | Si | Cr | Ni | Mo | Nb | Ti |
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | … | … . | … |
| TP304H | 0.04-0.10 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | … | … | … |
| TP304L | 0.035 D | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | … | … | … |
| TP310S | 0.08 | 2 | 0.045 | 0.03 | 1 | 24.0-26.0 | 19.0-22.0 | 0.75 | ||
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | … | … |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | … | … |
| TP316H | 0.04-0.10 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | … | … |
| TP316Ti | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | … | 5x(C+N)-0.70 |
| TP321 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-12.0 | … | … | 5C-0.70 |
| TP321H | 0.04-0.10 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-12.0 | … | … | 4C-0.60 |
| TP347 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-13.0 | 10xC-1.00 | … | |
| TP347H | 0.04-0.10 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-13.0 | … | 8xC-1.00 | … |
| Material | Heat Treatment | Temperure Min. F(C) | Tensile Strength Ksi (MPa), Min. | Yield Strength Ksi (MPa), Min. | Elongation %, Min |
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP304H | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP310S | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
| TP316H | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316Ti | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP321 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP321H | Solution | Cold: 2000(1100) Hot: 1925(1050) | 75(515) | 30(205) | 35 |
| TP347 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP347H | Solution | Cold: 2000(1100) Hot: 1925(1050) | 75(515) | 30(205) |
Product Details:
Product Application:
Certification:
Packaging & Shipping:
FAQ:
1. Are you a trading company or factory?
We are a manufacturer factory and we also have our own exporting license.
2. Do you have certificate ?
Yes, ISO, FDA, LFGB, CE, PED certificate . We also have some patents in design.
3. How do you control the quality?
In quality control ,the most important is to avoid material mixing .
In our factory , 3 spectro PMI machines are used in raw material warehouse, production plant, dispatch plant.
Pressure inspecting machine, PMI machines, RA roughness spector, hardness testing machine..... all machines help in inspection.
2 staff inspect during production in different sections
5 staff inspect the finished productions to avoid shortage, poor quality, mixing chemical....
4. If there is any quality problem, how do you solve it?
We are very proud that we never make one customer leave us. We are not 100% perfect, there is some quality problem.
Normally replacement, or compensation, or resend goods to customers as per the condition. To be discussed as per condition.
5. How long is your delivery time?
For normal products in 7-10 days; for bulk order, in 15-25 days. It depends.
